Electromagnetic Interference Filter 10A (250V)

Designed for mounting inside a chassis, these industry standard RF/EMI filters are pre-designed to reduice line-to-ground (common mode) interference. Rated for mains voltages of 125 or 240VAC 50 or 60Hz, they are very useful when mains cords are fixed to the outside chassis and an IEC320 inlet is not suitable.

Type - chassis mount.

MS-4001 Chassis Mount EMI Filter

Product Specifications

• Rated voltage: 250VAC, 50Hz
• Rated current: 10A
• Leak current: 0.8mA max
• Insulation resistance: 100Mohm min
• Attenuation: 1 - 50MHz
• Termination: PCB mounting pins (MS-4000) & solder tags (MS-4001)

• Length : 5 cm
• Width : 3.2 cm
• Height : 2.5 cm
